ACMAS301 - AC Service Station

ACMAS301 AC Service Station

Refrigerant Recovery, Recharge and Purifying Station

Works with R134a

DaTo ACMAS301 A/C Service Station is built for refrigerant recovering, recharging and purifying. Developed with durable components and reliable SCM control programs, this CE certified machine offers simple operation, LCD display, vehicle database and printer support for professional workshops.

Recovering and recycling with used oil discharge
Vacuum and vacuum leak test
New oil injection and refrigerant charging
Full automatic mode for recovery, vacuum, oil injection and charge
Unidirectional and bidirectional flush
A/C database included with USB update support
Thermal printer, condenser, cooling fan and heater band

Price: Enquiry Based Get Quote WhatsApp

CE CertifiedReliable workshop product

A/C Database4000+ car models

Thermal PrinterInstant service records

USB

USB UpdatesDatabase update support

Workshop ReadyBuilt for A/C service

Recovering & Recycling

Recover refrigerant and discharge used oil

Vacuum Test

Vacuum operation with leak test support

Oil Injection

New oil and UV dye injection support

Charging

Fast refrigerant charging up to 2 kg/min

Full Automatic Mode

Automatic recovery, vacuum, oil injection and charge

Flush Function

Unidirectional and bidirectional flushing

Automatic Air Purge

Air purge and recovery pause functions

A/C Database

1995-2010 database with over 4000 models

Description

Product Overview

Latest DaTo production for refrigerant recovering, recharging and purifying.
Developed with durable components and reliable SCM control programs.
CE certified and suitable for different workshop customer groups.
Simple operation with LCD display and full automatic service workflow.
Includes A/C database with USB update support.
Automatic service reminder after 600 operations.
Hand valve free operation with automatic air purge and recovery pause.
Abundant A/C database from 1995-2010 covering over 4000 car models.

Specifications

Input Power: AC220V +/-10% 50/60Hz or AC110V +/-10% 60Hz
Compressor Power: 3/8 HP
Recovery Speed: 350 g/min average gas state through charge/suction port
Recovery Rate: 99%
Vacuum Pump Capacity: 120 L/min
Flush Time: 10-60 min unidirectional/bidirectional
Drier-filter Capacity: 600 ml
Max Pressure: 20 bar

Capacity & Display

Gas Cylinder Load Cell: +/-10 g accuracy
Oil Bottle Load Cell: +/-5 g accuracy
Gas Cylinder Capacity: 13.6 L
New/Used Oil Bottle: 250 ml capacity
Charge Speed: 2 kg/min max.
LCD Display: 105.5 x 67.2 mm, 480RGB x 272 dots, TFT full color
HP Gauge Range: -1 to 40 bar
LP Gauge Range: -1 to 22 bar

ACMAS301 Workshop Features

Automatic ServiceFully automatic recovery, vacuum, oil injection and charge workflows.

Leak TestVacuum leak test with optional HP leak test support.

Smart RemindersAutomatic service reminder after 600 operations.

DatabaseA/C database included and updateable through USB port.

Oil DischargePressurization speeds up used oil discharge.

Cooling HardwareCondenser, cooling fan and heater band included.

DimensionsPackage: 720 x 670 x 1185 mm; unpacked: 635 x 585 x 1075 mm.

CatalogueWorks with R134a and supports professional A/C service workflows.

Need ACMAS301 for your workshop?

Talk to Datronix Autotech for pricing, product guidance and A/C service station support.

Get Quote -> WhatsApp Now
